Setup HTTPS for Matomo
Cette page est également disponible en français.
It almost became a reflex, as soon as we set up a web service: we secure it with an HTTPS connection.
In fact, the best thing to do is to first ask yourself the question: “is this relevant for this service?”. And if the answer is yes, then install the certificates and setup the connection.
After having installed matomo in our private network and having setup logging, we could indeed ask ourselves why so many efforts? After all, it can only be accessed locally ! The answer lies in two points:
- Defense in depth. Even if we do not use the tracker, if your data is anonymized, if the server can only be accessed locally and if statistics are accessible only after access control, we are not immune to error.
To be transparent with you, I appreciate when things are done well and getting my hands dirty for these certificate details, that relaxes me…
Deploy the certificate and the key
I’m assuming that you already know how to generate a certificate and its key. Otherwise, here’s how to generate them with XCA. For simplicity, I will also assume that you have exported these two files:
matomo.crtfor the certificate,
matomo.keyfor the key.
Unsurprisingly, these files must be uploaded to your Matomo server. Technically, you could put them wherever you want, but the tradition has two directories designed for that:
Like all traditions, you can chose to be rebels, it will work very well but you will have communication problems with your colleagues…
/etc/ssl/private/for the keys.
The advantage of using these two directories is that they are already setup to minimize the risk of leaks of this sensitive data.
But since a problem can always happen, we will do defense in depth (again and again) and change the rights of the two files (root owner and access rights):
sudo chown root:root /etc/ssl/certs/matomo.crt sudo chown root:root /etc/ssl/private/matomo.key sudo chmod 640 /etc/ssl/private/matomo.key
Why the root user and not www-data? Because when the application server starts, it does so with the identity of root, to open the network ports (80 and 443 that only root can open) and read its configuration. It is only once launched that it drop its privileges and changes to the identity www-data. At this point, there is no longer any justification for reading the configuration files.
Setup the web server
Since I am using a blank server and its default configuration, I will
modify the default configuration file for HTTPS connections:
Change the configuration. As these change are classics, you only have to look for the two lines of SSL/TLS directives concerning the certificate and the key and adapt the path to your files. Something like this:
SSLCertificateFile /etc/ssl/certs/matomo.crt SSLCertificateKeyFile /etc/ssl/private/matomo.pem
Enable HTTPS. By default, your
server has not yet enabled the module (
ssl) and virtual
HTTPS connections. Their activation is done in
three simple commands:
sudo a2enmod ssl sudo a2ensite default-ssl sudo service apache2 restart
Bonus : HSTS
Another defense in depth task, we can also setup the web server to notify browsers not to contact it through unsecured channels. We call that HTTP Strict Transport Security and in other words, it asks browsers to refuse to load resources or send data via HTTP and to use only HTTPS.
Nothing complicated to do, you have to add a directive line to the previous SSL/TLS vhost file:
Header always set Strict-Transport-Security "max-age=31536000; includeSubDomains"
For this to work, you must also activate the headers module which manages this configuration line and which will insert this header to HTTP responses. Two commands to launch and it will works:
sudo a2enmod headers sudo service apache2 restart
Force the HTTPS connection
Your site is now accessible in
HTTPS but some visitors
could still use
We could of course setup
apache2 to automatically
redirect all HTTP requests to HTTPS but as Matomo has something made
internally (this is even explained in the official
documentation, I prefer to go through it.
I agree: it is not a good practice to mix the layers and partially setup SSL/TLS in two different systems. But from experience, this kind of thing often hides technical debt and unpredictable side effects. So to avoid wasting hours in improbable debugging, I prefer to follow the documentation.
To force HTTPS connections, you must then modify the matomo
configuration file (from the Matomo directory:
config/config.ini) and uncomment the
[General] force_ssl = 1
The redirection will therefore not be done by apache2 but by matomo’s
PHP. So there is no need to enable
And after ?
Your application and your web server are now accessible via HTTPS, communications are secured by TLS. The HSTS makes it possible to avoid some forgotten resources being accessed in HTTP and Matomo will redirect these accesses to the HTTPS version anyway.
Of course, for it to be really secure, the CA that signed your certificate must be recognized by your users’ browsers. If you have your own PKI, that means deploying your CA to your visitors.
If your matomo is going to be accessible to anyone, it is going to be difficult to deploy your CA everywhere. In this case, going through an already recognized CA will make it easier for you (and in this case, you could use lets encrypt).
